The Ultra
Predictable, reliable, smart.
High throughput keeping you ahead of the game.
Our most advanced 3D printer yet.
Unrivalled 3D print monitoring technologies
Engineered to deliver production continuity in any environment.
Active Layer Monitoring
Asiga’s pioneering Smart Positioning System (SPS™) achieves precise layer thickness control of each and every layer, ensuring optimal print accuracy and speed.
4K Imaging Resolution
The latest high resolution imaging chipset delivers extraordinary resolution over a large build envelope.
Auto-Calibrating UV LED
Combining the latest generation of high-power ultraviolet solid-state light sources with an integrated radiometer ensures years of consistent printing performance.
385nm LED as standard.
DLP Micromirror Technology
Achieve the highest standard of reliability with the broadest wavelength capability of any imaging technology.
User features that actually make a difference.
No gimmicks. Functional, useful features to make your workflow easier.
Touchless Entry
Interact with your 3D printer without contaminating surfaces or double handling.
Give the Ultra a wave and watch the hood open effortlessly. Manual opening also possible!
Magnetic Platform Holder
Streamline your workflow and be automation ready with the new magnetic build-platform holder. No latches, screws or calibration is necessary.
Infrared Material Heater
Access a new generation of advanced materials with the infrared material heating system.
Achieve temperatures up to 70°C.
User-centered design.
Award winning.
With a proud history that dates back to 1958, the Good Design Awards remains committed to promoting the importance of design to business, industry, government and the general public and the critical role it plays in creating a better, safer and more prosperous future.
The Ultra has been awarded a Good Design Award for the category:
Product Design: Medical and Scientific
An intuitive User Interface (UI)
Clean, intuitive, modern, simple.
All the buzz words to describe our simplest UI to-date.
Transparent Mode™
True water-clear resins can now be printed with extreme precision.
No more blooming or over-curing with Asiga’s Transparent Mode™
Chamber Heating
Ensure optimal process repeatability with built-in chamber temperature control.
Have your 3D printer warm materials so they are ready to go when you are.
Material Freedom
Over 500 materials available.
Experience the widest choice of materials on the market with unlimited and unrestricted access to many industry-leading materials for a variety of applications. Future-proof your business and stay up-to-date with the latest validated 3D print materials thanks to Asiga’s Open Material Architecture.
Material Freedom
Over 500 materials available.
Experience the widest choice of materials on the market with unlimited and unrestricted access to many industry-leading materials for a variety of applications. Future-proof your business and stay up-to-date with the latest validated 3D print materials thanks to Asiga’s Open Material Architecture.
Simple & quick material change-over
Our smart material tray clamping system allows you to rapidly switch materials when deadlines are tight.
Change materials in less than 30 seconds. No calibration required.
Unlimited lifetime technical support
Receive technical support from your local reseller and also from any of our global offices. Asiga technical support is unlimited and free.
Powerful nesting software
Asiga Composer provides an intuitive interface for you to manage production on your Asiga 3D printer. Automatic set-up features including automatic part placement, automatic supports, full access to advanced settings where required. Enjoy unlimited installs and all future software updates.
Technical specifications
| Product specification | Ultra (32) | Ultra (50) |
|---|---|---|
| Build Volume X, Y, Z | 121 x 68 x 147mm 4.76 × 2.67 × 5.78 inches | 192 x 108 x 147mm 7.55 × 4.25 × 5.78 inches |
| Pixel Size | 32µm | 50µm |
| Technology | DLP | DLP |
| Auto-calibrating UV LED | 385nm (365nm and 405nm available on request) | 385nm (365nm and 405nm available on request) |
| Material Compatibility | Use any one of over 500 qualified resins from the world's leading material manufacturers, or create your own. |
|---|---|
| Software | Asiga Composer software. Lifetime updates included |
| File Inputs | STL, SLC, PLY, STM (Asiga Stomp file format) |
| Network Compatibility | Wifi, Wireless Direct, Ethernet |
| Power Requirements | 100-240VAC / 500Watts |
| System Sizing | 353 x 441 x 555mm | Weight 32.5Kg .. 13.9 x x 17.3 x 21.8 inches | Weight 71.5 Lbs |
| Packed Sizing | 485 × 615 × 799mm | Weight 44 Kg .. 19 × 24.21 × 31.45 inches | Weight 97 Lbs |
| Warranty | 12 months manufacturer's warranty |
| Technical Support | Unlimited lifetime technical support included |
| Bundle Includes | 3D printer, Composer software, 1kg Asiga material, 2L build tray, Asiga Flash post-curing chamber, calibration toolkit |
What’s included
Included with your Ultra is everything you need to get started.
• Ultra 3D printer
• Calibration toolkit
• Asiga material of your choice and build tray
• Asiga Flash curing chamber
• Composer software
• Unlimited lifetime technical support
Future-proof your production capabilities
